SIMATIC ET 200SP, digital output module, DQ 16x 24VDC/0.5A Basic, Pack quantity: 1 unit, suitable for BU type A0, Color code CC00, Module diagnostics General information Product type designation DQ 16x24VDC/0.5A BA HW functional status From FS03 Firmware version V0.0 ● FW update possible No usable BaseUnits BU type A0 Color code for module-specific color-coded label CC00 Product function ● I&M data Yes; I&M0 to I&M3 ● Isochronous mode No Engineering with ● STEP 7 TIA Portal configurable/integrated from version V14 ● STEP 7 configurable/integrated from version STEP 7 V5.5 or higher ● PROFIBUS from GSD version/GSD revision One GSD file each, Revision 3 and 5 and higher ● PROFINET from GSD version/GSD revision GSDML V2.3 Operating mode ● DQ Yes ● DQ with energy-saving function No ● PWM No ● Oversampling No ● MSO No Supply voltage Rated value (DC) 24 V permissible range, lower limit (DC) 19.2 V permissible range, upper limit (DC) 28.8 V Reverse polarity protection Yes Input current Current consumption, max. 55 mA; without load Output voltage Rated value (DC) 24 V Power loss Power loss, typ. 1 W Address area Address space per module ● Outputs 2 byte Hardware configuration Automatic encoding Yes ● Mechanical coding element Yes ● Type of mechanical coding element Type A Selection of BaseUnit for connection variants ● 1-wire connection BU type A0 ● 2-wire connection BU type A0 + Potential distributor module ● 3-wire connection BU type A0 + Potential distributor module ● 4-wire connection BU type A0 + Potential distributor module Digital outputs Type of digital output Source output (PNP, current-sourcing) Number of digital outputs 16 Current-sinking No Current-sourcing Yes Digital outputs, parameterizable Yes Short-circuit protection Yes ● Response threshold, typ. 1.4 A; 0.7 to 1.9 A Open-circuit detection No Limitation of inductive shutdown voltage to Typ. L+ (-53 V) Controlling a digital input Yes Switching capacity of the outputs ● with resistive load, max. 0.5 A ● on lamp load, max. 5 W Load resistance range ● lower limit 48 Ω ● upper limit 100 kΩ Output current ● for signal “1” rated value 0.5 A ● for signal “0” residual current, max. 30 µA Output delay with resistive load ● “0” to “1”, typ. 80 µs; at rated load ● “0” to “1”, max. 150 µs; at rated load ● “1” to “0”, typ. 100 µs; at rated load ● “1” to “0”, max. 200 µs; at rated load Parallel switching of two outputs ● for uprating No ● for redundant control of a load Yes Switching frequency ● with resistive load, max. 100 Hz ● with inductive load, max. 2 Hz ● on lamp load, max. 10 Hz Total current of the outputs ● Current per channel, max. 0.5 A ● Current per module, max. 8 A Total current of the outputs (per module) horizontal installation — up to 60 °C, max. 8 A vertical installation — up to 50 °C, max. 8 A Cable length ● shielded, max. 1 000 m ● unshielded, max. 600 m Interrupts/diagnostics/status information Diagnostics function Yes Substitute values connectable Yes Alarms ● Diagnostic alarm Yes Diagnoses ● Monitoring the supply voltage Yes ● Wire break No ● Short-circuit No ● Group error Yes Diagnostics indication LED ● Monitoring of the supply voltage (PWR-LED) Yes; green PWR LED ● Channel status display Yes; green LED ● for channel diagnostics No ● for module diagnostics Yes; green/red DIAG LED Potential separation Potential separation channels ● between the channels No ● between the channels and backplane bus Yes Isolation Isolation tested with 707 V DC (type test) Standards, approvals, certificates Suitable for safety functions No Suitable for safety-related tripping of standard modules No Ecological footprint ● environmental product declaration Yes Global warming potential — global warming potential, (total) [CO2 eq] 29.3 kg — global warming potential, (during production) [CO2 eq] 3.98 kg — global warming potential, (during operation) [CO2 eq] 25.6 kg — global warming potential, (after end of life cycle) [CO2 eq]
