S7-1200 G2 by SIEMENS

SM 1221 Digital Input , 16DI - 6ES7221-1BH50-0XB0

INR 1
DATASHEET
In stock

Description

SIMATIC S7-1200 G2: SM 1221 digital input, 16 DI; inputs: 16x DI 24 V DC sink/source

General information

Product type designation SM 1221, DI 16x 24 V DC

Input current

from backplane bus 5 V DC, max. 90 mA

Digital inputs

● from load voltage L+ (without load), max. 4.1 mA; per channel

Power loss

Power loss, typ. 3.2 W

Digital inputs

Number of digital inputs 16

● in groups of 4

Input characteristic curve in accordance with IEC 61131, type 1 Yes

Number of simultaneously controllable inputs

horizontal installation

— up to 40 °C, max. 16

— up to 50 °C, max. 16

vertical installation

— up to 40 °C, max. 16

Input voltage

● Rated value (DC) 24 V

● for signal “0” 5 V DC or 0.5 mA

● for signal “1” 15 V DC at 2.5 mA

Input current

● for signal “0”, max. (permissible quiescent current) 0.5 mA

● for signal “1”, min. 2.5 mA

● for signal “1”, typ. 4.1 mA

Input delay (for rated value of input voltage)

for standard inputs

— Parameterizable Yes; 0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms and 12.8 ms, selectable in groups of four

for interrupt inputs

— parameterizable No

Cable length

● shielded, max. 500 m

● unshielded, max. 300 m

Interrupts/diagnostics/status information

Diagnostics function Yes

Alarms

● Diagnostic alarm No

Diagnoses

● Monitoring the supply voltage No

Diagnostics indication LED

● for status of the inputs Yes

● for maintenance Yes

Potential separation

Potential separation digital inputs

● between the channels, in groups of 4

● between the channels and backplane bus Yes; 707 V DC (type test)

Isolation

Isolation tested with 707 V DC (type test)

Degree and class of protection

IP degree of protection IP20

Standards, approvals, certificates

Siemens Eco Profile (SEP) Siemens EcoTech

CE mark Yes

CSA approval No

UL approval Yes

cULus Yes

FM approval No

RCM (formerly C-TICK) Yes

KC approval Yes

Marine approval No

Ecological footprint

● environmental product declaration Yes; type 2 acc. to ISO 14021

Global warming potential

— global warming potential, (total) [CO2 eq] 40.3 kg

— global warming potential, (during production) [CO2 eq] 7.79 kg

— global warming potential, (during operation) [CO2 eq] 32.5 kg

— global warming potential, (after end of life cycle) [CO2 eq] -0.089 kg

Ambient conditions

Free fall

● Fall height, max. 0.3 m; five times, in product package

Ambient temperature during operation

● horizontal installation, min. -20 °C

● horizontal installation, max. 60 °C; at max. voltages and max. specification

● vertical installation, min. -20 °C

● vertical installation, max. 50 °C; at max. voltages and max. specification

Ambient temperature during storage/transportation

● min. -40 °C

● max. 70 °C

Air pressure acc. to IEC 60068-2-13

● Operation, min. 540 hPa

● Operation, max. 1 140 hPa

● Storage/transport, min. 540 hPa

● Storage/transport, max. 1 140 hPa

Altitude during operation relating to sea level

● Installation altitude, min. -1 000 m

● Installation altitude, max. 5 000 m; Restrictions for installation altitudes > 2 000 m, see manual

Relative humidity

● Operation at 25 ℃ without condensation, max. 95 %

Vibrations

● Vibration resistance during operation acc. to IEC 60068-2-6 3.5 mm from 5 - 8.4 Hz, 1g from 8.4 - 150 Hz

● Operation, tested according to IEC 60068-2-6 Yes

Shock testing

● tested according to IEC 60068-2-27 Yes; IEC 68, Part 2-27 half-sine: strength of the shock 15 g (peak value), duration 11 ms

Pollutant concentrations

● SO2 at RH < 60% without condensation S02: < 0.5 ppm; H2S: < 0.1 ppm; RH < 60 % condensation-free

Connection method

required front connector No

Mechanics/material

Enclosure material (front)

● plastic Yes

Dimensions

Width 30 mm

Height 125 mm

Depth 100 mm

Weights

Weight, approx. 166 g
